LD81M

Description

The LD81M is a smaller, more discreet version of the LD81, using the same LED, optics and mounting methods. It utilises the latest LED technology with a typical CRI of 93 in warm white as well as a beam that can be precisely controlled with a range of optics. Each mounting method is custom made to each projects requirements, allowing the designer to tailor the lighting layout for each display. The best method of specification for these spotlights and mounting systems is to send us a sketch of what is required. This can then be discussed and we will produce a project specification and quote.



Applications

Display and Shelf, Picture Lighting, Surface Mounted

Fixing

Knuckle joint (supplied with nut and washer) with up to 9x mounting options

LED Information

NICHIA C1 LED Engine: 1.2W @ 350mA (LD81M-C1-350)

Materials

Painted anodised aluminium

IP Rating

IP40

Downloads

LD81M
LD81M Datasheet
LD81M
Design Pack
LD81M
Photometric LDT
Files
LD81M
Install Instructions
LD81M
Drivers
